Descriere
Categorie | |
Tip | Home |
Porturi | |
Port LAN/WAN | Da |
Porturi LAN | 3x LAN |
Porturi WAN | 1x WAN |
Porturi LAN/WAN | 10/100 Mbps |
General | |
Frecventa | 2.4 GHz |
Standarde | 802.11 b/g/n |
Viteza transfer wireless | 300 Mbps |
Alimentare | 12V, 1A |
Management | Access Control |
Protocoale suportate | IPv4 |
VPN | VPN Pass Through |
DNS | DynDns |
Securitate | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Firewall | DoS |
Dimensiuni | 202 x 141 x 33.6 mm |
Routing | Virtual Server |
Restart programabil | Da |
Caracteristici WLAN | Dynamic IP |
Internet Mobil | |
Compatibil 3G | Da |
Compatibil 4G | Da |
Suport SIM | Integrat |
Hardware | |
Tip antena | Externa |
Detalii
SKU
TL-MR6400
Categorii
Brand
Product colour
Black
Ethernet LAN
Yes
Mobile network connection
Yes
Mobile network generation
4G
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 C
AC adapter included
Yes
DC-in jack
Yes
Quick start guide
Yes
Reset button
Yes
Quality of Service (QoS) support
Yes
Cables included
LAN (RJ-45)
Ethernet LAN (RJ-45) ports
4
DHCP server
Yes
ADSL
No
WAN-Ports
1
Indication light
Yes
Harmonized System (HS) code
85176990
Universal Plug and Play (UPnP)
Yes
4G standard
LTE
Quick installation guide
Yes
Power source type
DC
DHCP client
Yes
Firewall
Yes
Ethernet WAN
Yes
SIM card slot
Yes
USB-Port
Yes
Frequency-Band
SingleBand
Web-based management
Yes
Port forwarding
Yes
Package weight
600 g
Output voltage
12 V
Network address translation (NAT)
Yes
Guest access
Yes
DSL WAN
No
3G/4G USB modem compatibility
No
DMZ support
Yes
Access Control List (ACL)
Yes
LED indicators
Yes
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
Storage temperature (T-T)
-40 - 70 C
On/off switch
Yes
Product type
Tabletop router
Wi-Fi band
Single-band (2.4 GHz)
WR-LAN-Ports
3
Rack mounting
Yes
Ethernet LAN data rates
10,100 Mbit/s
Certification
CE, FCC, Rohs
Linux operating systems supported
Yes
Storage relative humidity (H-H)
5 - 90%
Output current
1 A
Cabling technology
10/100Base-T(X)
DoS attack prevention
Yes
Mac operating systems supported
MacOS
Package height
70 mm
Package depth
223 mm
GSM bands supported
850,900,1800,1900 MHz
Detachable antenna(s)
Yes
Wi-Fi standards
802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antennas quantity
4
Frequency band
2.4 GHz
WPS push button
Yes
Windows operating systems supported
Windows 10, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Wi-Fi Multimedia (WMM)/(WME)
Yes
Ethernet LAN interface type
Fast Ethernet
Height
33.5 mm
Parental control
Yes
Dynamic DNS (DDNS)
Yes
Number of guest networks (2.4 GHz)
1
Port triggering
Yes
Stateful Packet Inspection (SPI)
Yes
WAN connection type
RJ-45
Supported network protocols
IPv4, IPv6
Security algorithms
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antenna design
Internal & external
Port-Type
FastEthernet
WiFi-Standard
b/g/n
3G standards
HSPA+, UMTS
Wireless-Speed
150Mbps
VPN Passthrough
Yes
3G
Yes
4G
Yes
Package width
307 mm
Width
202 mm
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Memory card slot(s)
No
WLAN data transfer rate (max)
300 Mbit/s
WLAN data transfer rates supported
11,54,300 Mbit/s
UMTS bands supported
900,2100 MHz
2G standards
Edge, GPRS, GSM
Firewall security
DoS, SPI Firewall, IP and MAC Address Binding
VPN support
PPTP, L2TP, IPSec
VPN server
PPTP VPN, IPSec VPN , OpenVPN
Bandwidth (first)
2.4 GHz
Supported WAN type
RJ-45
SIM
4G bands supported
800,900,1800,1900 MHz
xDSL connection
No
USB ports quantity
0
Depth
14.1 mm
