Descriere
General | |
Chipset | Realtek |
Modalitate conectare | USB 2.0 |
Standarde | 802.11 b/g/n |
Frecventa de operare | 2.4 GHz |
Antena | Interna |
Modulatie | OFDM/CCK/16-QAM/64-QAM |
Securitate | WPA-PSK/WPA2-PSK (TKIP/AES) |
Dimensiuni | 93.5 x 26 x 11 mm |
Detalii
SKU
TL-WN821N
Categorii
Brand
Storage relative humidity (H-H)
5 - 95%
Sustainability compliance
Yes
Wi-Fi
Yes
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 C
Quick start guide
Yes
Harmonized System (HS) code
85176990
Quick installation guide
Yes
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
Storage temperature (T-T)
-40 - 70 C
Wi-Fi band
Single-band (2.4 GHz)
Antenna design
Internal
Internal
No
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Linux operating systems supported
Yes
Component for
PC/Laptop
Product colour
Black, White
Package depth
137 mm
Wi-Fi standards
802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables included
USB
Resource CD
Yes
Host interface
USB
USB powered
Yes
Package weight
150 g
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
WPS push button
Yes
Height
12 mm
Transmitting power (FCC)
20 dBm
Maximum data transfer rate
300 Mbit/s
Package width
148 mm
Width
86 mm
Depth
26 mm
Transmitting power (CE)
20 dBm
Connectivity technology
Wireless
Antenna
Yes
Package height
42 mm
Interface
WLAN
WiFi-Standard
b/g/n
Operating modes
Infrastructure mode
Frequency range
2.4 - 2.4835 GHz
WLAN data transfer rates supported
11,54,300 Mbit/s
Supported network protocols
CSMA/CA, ACK
Mac operating systems supported
Mac OS X 10.15 Catalina
Modulation
16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
